ECL-88 Dual flow high-temperature and high-speed dyeing machine

  The current elastic cloth,as full cotton elastic cloth,spiral glutinous elastic cloth,polyester terylene elastic cloth and nylon elastic cloth,etc.

  • The liquor flow and jet water flow are optional, soft water flow to guarantee the dye things from furried, and the yarn branch from distort. Weight of the code varies from 60~600g/ m 2 .
  • Combined change long attitude cloth guide pipe, which can reduce to the lowest tension and it is of the function of eliminating the radius fold.
  • Short cloth groove,proper cloth length,low bath ratio,with easy operation and maintenance.
  • Low height of the machine table,low tension,to make the low shrinkage ratio after the dye.

◆Standard structure

  • Machine body and major parts wetted by dyeing liquid are made of highly corrosion resistant stainless steel
  • Florin pipe spread in the cloth store groove
  • Heavy duty stainless steel centrifugal pump
  • Lifter reel driven by frequency inverter controlled motor
  • Dual-flow nozzle
  • Pneumatic control valves for heating and cooling,with temperature control function
  • Pneumatic valve for fill and drain function
  • Internal spray cleaning device
  • High efficiency heat exchanger
  • Body shell pressurizing and depressurizing system
  • Level indicator with level sensor
  • Service tank with feed pump,valves,stirring function
  • Take off roller
  • Spare filter insert
  • Service platform
  • Main control cabinet micro processor


  • Layout platier Coupling accessories
  • second fill,second drain
  • Dosing control with precision flow control device
  • Second service tank with individual feed pump, valves, trring function
  • Seam detector

Each tubes separates into two chamber(running two ropes at same time-see diagramed)
Each chamber loading capacity 125kg
Big bend tube can save 10% water & space
Excellent result for new fashion fabrics

◆Technique data of accessories

  • Constant liquor ratio :1:6
  • Maximum working temperature :140°C
  • Heating rate :20°C~140°C average 35min
  • Cooling rate :140°C~60°C average 30min
  • Speed:Jet flow 0~450m/min
    Overflow 0~250m/min

Type No. of Tubes/chambers Max. Capacity kg Total Power kw Dimensions
L1(mm) L2(mm) W(mm) H1(mm) H2(mm)
ECL-88-25 1/1 18-25 9.4 3810 5240 1450 1910 2730
ECL-88-50 1/1 35-50 10.2 4900 6350 1450 1910 2730
ECL-88-75 1/1 50-75 10.2 5400 6830 1530 1910 2730
ECL-88-100 1/2 70-100 13.5 4700 5800 1700 2300 3080
ECL-88-250 1/2 175-250 18 6990 8090 1700 2300 3080
ECL-88-500 2/4 350-500 36 6990 8090 3100 2300 3080
ECL-88-1000 4/8 700-1000 63.5 6990 8090 6050 2400 3180
